The Spanish SH-60F, manufactured by Sikorsky Aircraft, is a 4-blade, two-turbine single-rotor helicopter. It is a naval helicopter, for amphibious helicarrier (TTH).
It has a barycentric hook for logistics tasks, which allows the transport of external loads for vertical supply (VERTREP). It also has a loading crane (hoist), which facilitates the ability to lift or lower objects or people inside the helicopter (VOD).
To meet medical evacuation capabilities (CASEVAC/MEDEVAC), it has a medicalization kit to install stretchers, in addition to the possibility of installing medical equipment that allows stabilized medical evacuation.
Currently, the helicopter mounts the 12.7 mm GAU-16 machine gun, and the acquisition of the 7.6 mm M-240D is planned.
WEIGHT: Maximum takeoff: 21,883 Lbs.
MAIN ROTOR DIAMETER: 16.35 meters.
HEIGHT: 3.8 meters.
AUTONOMY: 4 hours (possibility of HIFR-Hot In Flight Refueling).
CREW: According to mission, minimum 2 pilots, 1 crew.
ARMAMENT: GAU-16 / M-240D machine gun.
CEILING: 13,000 feet.
SPEED: 180 Kts maximum and 140 Kts cruise
The EH 101 is a medium/heavy platform capable of performing multiple tasks including: Anti-Submarine and Anti-Ship Warfare, Air-Naval Operations Command and Control, Search and Rescue (SAR) and Maritime Patrol/Assault.
- Length: 22.77 meters
- Dimensions with rotors in motion: 18.60 meters
- Height: 6.61 meters
- Maximum weight: 15,600 kg
- Maximum speed: 220 - 280 km/h (120 - 150 knots)
- Engine: 3 General Electric T700 / T6 A turboshaft engines
- Maximum range: 5 hours
- Crew: 2 pilots and 2 flight technicians
- Armament (ASW configuration):
- 4 x MK 46 / MU90 torpedoes
- Armament (ASUW configuration):
- 2 x MARTE air/surface missiles
- 2 x MS 500 bombs
- 2 x MG machine guns
- 4 x CHAFFS launchers
